Sage ICS7a

SAGE SERIES iCS7a

Point Source In-Ceiling Multifunctional Loudspeaker

The Sage Series iCS7a in-ceiling speaker is the World’s First multi-functional planar magnetic (PMD) round in-ceiling loudspeaker. Its 6-Bar PMD is completely new and is based upon Wisdom’s award-winning Sage P20 driver. It represents a breakthrough in the power shading capabilities of Wisdom Audio’s planar magnetic driver (PMD), delivering a fully passive Sage Series point-source product that’s capable of achieving high output down to 57Hz.

To ensure maximum clarity, the angled PMD design allows the on-axis energy to be focused straight at the listening area. The system does not require active crossover or bi-amplification, allowing dealers to offer Sage Series performance at a lower price point.

Key Features

Highly Detailed & Dynamic
(1) 6-Bar Planar Magnetic Driver
Covers 5 Octaves of Clarity
Light Weight Film PEEK
FAST Acceleration

Angled PMD Design
Includes an Optional Extended Coverage Waveguide – ECW that is designed to enhance its polar pattern and allow for greater placement options.
Optional Laser Alignment (IC-LAT) tool created to assist installers in achieving ultra-precise driver orientation, improving focus and delivering incredible imaging.
Optional Square Grille (IC7-SGK).
Optional In-Ceiling Flush Plaster Mounting Platform by SeeLess (SL-WICS7R-062). This can be ordered directly from SeeLess (currently this is only available to US dealers).

The Perfect Product for Multiple Applications:
  Hi-Fi 2-Channel In-Ceiling Stereo
  Distributed Audio Zones
  In-Ceiling Side & Rear Channels
  In-Ceiling LCR
  In-Ceiling Immersive Audio Applications

Full Range Loudspeaker
(1) High Operating Woofer
Passive Crossover
1-CH’s of Amplification Required

Specification

Frequency Response57Hz – 20kHz +/- 3 -6dB at 50Hz
Impedance4.5 ohms
Sensitivity87dB
Minimum Recommended Power 50 Watts
Max Continuous Power Handling300 Watts
Peak Power600 Watts
Round Grille O.D.11.57″ (29.4 cm
Square Grille O.D.11.57″ (29.4 cm)
Speaker Depth6.473″ (16.4 cm) from the back of mounting flange to back box
Cutout Dimension10-1/8″ (25.9 cm)
Shipping Weight16 lbs. (7.3 kg)
Dimensions HxWxD11.57” x 11.57” x 6.57” (29cm x 29cm x 16.4cm)

Resources

PDF File Icon

iCS7A Owner’s Manual

PDF File Icon

iCS7A Info Sheet

PDF File Icon

iCS7A Accessory Info Sheet

PDF File Icon

iCS7A Drawing (PDF)

DWG File Icon

iCS7A Drawing (DWG)

PDF File Icon

iCS7A Optional Square Grille Dimensions

PDF File Icon

iCS7A Optional Square Grille Landing Pad Dimensions

PDF File Icon

Wisdom Audio Grille Painting Instructions

PDF File Icon

IC-BB Fire Rated Back Box Installation Manual
