Point Source

SAGE CINEMA POINT 2 V2

Point Source In/On-Wall/Ceiling Horizontal/Vertical Loudspeaker

Flexibility was also the mantra in developing the Sage Cinema Series Point 2 V2 speaker. The Point 2 V2 includes an all-passive crossover network allowing it to be driven by only a single amp channel. The Point 2 V2 and the ISC7a are the only two products within the Sage Series that do not require any outboard DSP or PEQ (pre-EQ). The Point 2 PMD module can be rotated 90 degrees and tilted 22.5 degrees, providing any seat in the room the benefits of Wisdom Audio’s signature clarity for vertical, horizontal, DOLBY ATMOS®, DTS: X®, and AURO-3D® installations.

Key Features

Highly Detailed & Dynamic
(1) Planar Magnetic Driver
Covers 5 Octaves of Clarity
Light Weight Kaptonn Film
FAST Acceleration

On-Wall / In-Wall / In-Ceiling (Behind Screens and or Fabric Walls)
Rotatable PMD for Horizontal or Vertical Installations
Angled PMD for use with In-Ceiling LCR, Surrounds, or Immersive Audio Applications

CAB – Point 2 : Custom Angle Bracket. Must specify angle degree needed when ordering – Ordered in pairs one pair per speaker needed

Full Range Loudspeaker
(1) High Operating Woofer
No Outboard DSP or PEQ Required
(1) CH of Power Amplification

Specification

Frequency Response60Hz – 20kHz
Impedance4 Ohms
Sensitivity87 dB
Peak Power600 Watts
Power Handling, Continuous200 Watts
Shipping Weight40 lbs. (18 kg)
Dimensions HxWxD22.38” x 11” x 6.71” (56.8cm x 27.9cm x 14cm)

Resources

youtube

Point 2 V2 Mounting Video

PDF File Icon

Point 2 V2 Owner’s Manual

PDF File Icon

Point 2 V2 Drawing (PDF)

DWG File Icon

Point 2 V2 Drawing (DWG)
