S10 sub v4


HiFi Test 2021 Germany P2m L75 SCS S10. 142x142 1

Free-Standing Subwoofer

The S10 (10”) Passive Subwoofer is a versatile unit capable of producing powerful clean bass from an incredibly compact cabinet. Convertible from freestanding upright to down-firing or up-firing installation, the ultra-compact design can easily be hidden under sofas or cabinets. At only 4.5” (116mm) deep and featuring a sealed cabinet, the stylish S10 is discreet and easy to install. Two S10 subwoofers can be powered by a single SW-1 DSP Amplifier. Available in luxurious high gloss white or black finishes. Both colors come with matching color magnetic grilles.

Key Features

Highly Detailed & Dynamically Accurate
(1) High-Output 10″ Woofer
Sealed Enclosure

Multiple placement options:

Frequency Response Across a 35Hz-80Hz Operating Range
(1) High Operating 10″ Woofer
(1) Channel of Power Amplification per Subwoofer Required


Frequency Response35Hz – 80 Hz
Impedance8 ohms
Sensitivity89 dB / 2.83 V / 1m
Recommended Amplifier Power370W w/DSP
Maximum SPL114 dB
Upright/Standing Weight39 lbs. (17.7 kg)
Dimensions – HeightUpright including feet = 15.95″ (40.5cm)
Down-firing including feet = 6.06″ (15.4cm)
Dimensions With Grille – Width x Height15.354” x 5.039” (39cm x 12.8cm)
Dimensions Without Grille – Width x Height15.354” x 4.567” (39cm x 11.6cm)


PDF File Icon

S10 Owner’s Manual

PDF File Icon

S10 Spec Sheet

PDF File Icon

S10 Down Firing Drawing (PDF)

DWG File Icon

S10 Down Firing Drawing (DWG)

PDF File Icon

S10 Standing Drawing (PDF)

DWG File Icon

S10 Standing Drawing (DWG)

PDF File Icon

Insight On-Wall Series Brochure
